HI-6110 (BUS MONITOR MODE)
EXAMPLE MT MIL-STD-1553 MESSAGE SEQUENCES
Example 11. Broadcast Mode Code with Data Word
The HI-6110 RT receives a Broadcast Mode Command with Data
word from the MIL-STD-1553 bus. The host reads the Mode Data
word received.
Host Read MODE (Mode Data)
Host Read CW1 (Command Word)
STR
Mode Code
Command
Mode
Data
MIL-STD-1553 Bus
From HI-6110 BC
VALMESS
RCVA/B
FFEMPTY
DATA BUS TIMING DIAGRAMS
DATA BUS TIMING - WRITE
DATA BUS TIMING - READ
REG
VALID
ADDR
REG
VALID
ADDR
tAWH
tARH
tAWS
tARS
tSTR
tSTR
STR
STR
tDWS
tDRS
tDRH
tDWH
DATA
BUS
VALID
VALID
DATA
BUS
tCSRS
tCSWS
tCSRH
tCSWH
CS
CS
tRWRS
tRWWS
tRWRH
tRWWH
R/W
R/W
Figure 4.
Refer to AC Electrical Characteristics Table
Figure 5.
Refer to AC Electrical Characteristics Table
HOLT INTEGRATED CIRCUITS
30
