HT45R37
PWM Programming Example
The following sample program shows how the PWM output is setup and controlled.
mov a,64h
mov pwm0h,a
clr pwm0l
clr pdc.0
set pwm0en
set pd.0
; setup PWM0 value to 1600 decimal which is 640H
; setup PWM0H register value
; setup PWM0L register value
; setup pin PD0 as an output
; set the PWM0 enable bit
; Enable the PWM0 output
:
:
:
:
clr pd.0
; PWM0 output disabled - PD0 will remain low
