PIN DESCRIPTIONS
NUMBER
SYMBOL
TYPE
DESCRIPTION
78
CLIP_TRS
TRS_ERR
ANC_DATA
I
Clip and TRS correction control. When HIGH, the TRS Blanking, ITU-R-601 clipping and TRS
insertion features are enabled.
79
80
O
O
TRS error indication. When HIGH, indicates a TRS error in the data stream such as a missing
TRS, an improperly placed TRS, or an incorrect TRS ID word.
Ancillary data indication. When HIGH, indicates that an ANC packet is coming out of the
device. The output is high from the beginning of the first header word to the end of the
checksum word of the ANC packet.
1, 4, 13
2, 3, 14
69
VDD
GND
SVDD
Power supply connection for the serial processing circuitry (nominally +5V).
Ground connection for the serial processing circuitry.
Power supply connection for the serial data outputs. To save power when not using the SDO/
SDO outputs, set this pin to ground.
72
SGND
Ground connection for the serial data outputs.
5, 8
VDD_SDI, SDI
Power supply connection for the internal 75 ohm pullup resistor (nominally +5V) on the serial
data input lines.
9, 12
VDD_SCI, SCI
Power supply connection for the internal 75 ohm pullup resistor (nominally +5V) on the serial
clock input lines.
29,51,68
30,50,67
VDD
GND
Power supply connection for the parallel processing circuitry (nominally +5V).
Ground for the parallel processing circuitry.
FLAG_MAP
HOSTIF_MODE
I²C
INTERFACE
EDH FLAG
EXTRACTION
HOST INTERFACE/
FLAG PORT
DEDICATED
FLAG PORT
8-BIT
PARALLEL
INTERFACE
CRC
COMPARISON/
CALCULATION
ERRORED
FLAGS
FIELD
COUNTER
10
BYPASS_EDH
FRAMED
DATA [9:0]
VBLANKS/L
ANCILLARY
CHECKSUM
ERROR FLAGS
10
CALCULATION/
COMPARISON
10
&
FLYWDIS
H, V, F
DOUT[9:0]
MUX
FORMAT PACKET
TRS
DETECTION
HVF
FLYWHEEL
5
CRC_MODE
ANCILLARY
CHECKSUM
CORRECTION
TRS
COMPARE
TRS_ ERROR
I²C is a registered
Trademark of Philips
NEW CRC
CALCULATION
10
ITU-R-601 CLIPPING
TRS BLANKING
TRS INSERTION/
CORRECTION
10
BLANK_EN CLIP_TRS
BLOCK DIAGRAM - EDH AND DATA CORE PROCESSING
7 of 31
19922 - 3
