Table 4-4: Switch Line Position for Digital Systems (Continued)
System
Video Format
Sampling
Signal
Standard
Parallel
Interface
Serial
Interface
Switch Line
No.
525
720x483/59.94 (1:1)
720x483/59.94 (1:1)
720x483/59.94 (1:1)
720x483/59.94 (1:1)
720x576/50 (1:1)
720x576/50 (1:1)
720x576/50 (1:1)
720x576/50 (1:1)
720x576/50 (1:1)
960x576/50 (2:1)
960x576/50 (2:1)
720x576/50 (2:1)
720x576/50 (2:1)
720x576/50 (2:1)
720x576/50 (2:1)
720x576/50 (2:1)
720x576/50 (2:1)
4:2:2
4:2:2
4:2:0
4:2:0
4:2:2
4:2:2
4:2:2
4:2:0
4:2:0
4:2:2
4:2:2
4:4:4:4
4:4:4:4
4:4:4:4
4:4:4:4
4:2:2
4:2:2
293M
347M
293M
349M
293M
349M
347M
BT.1358
349M
BT.1358
349M
BT.656
349M
347M
BT.799
BT.799
349M
125M
344M
294M
292M
294M
292M
344M
BT.1362
292M
BT.1362
292M
259M
292M
344M
344M
10
293M
10
293M
10
293M
10
625
BT.1358
BT.1358
BT.1358
BT.1358
BT.1358
BT.601
BT.601
BT.799
BT.799
BT.799
BT.799
BT.601
BT.601
6
6
6
6
6
6, 319
6, 319
6, 319
6, 319
6, 319
6, 319
6, 319
6, 319
292M
259M
4.7.4 HVF Timing Signal Generation
The GS1559 extracts critical timing parameters from either the received TRS signals
(FW_EN/DIS = LOW), or from the internal Flywheel-Timing Generator (FW_EN/DIS =
HIGH).
Horizontal blanking period (H), Vertical blanking period (V), and even/odd Field (F)
timing are all extracted and presented to the application layer via the H:V:F status
output pins.
The H signal timing is configurable via the H_CONFIG bit of the internal
IOPROC_DISABLE register as either active line based blanking, or TRS based blanking,
(see Error Correction and Insertion on page 53).
Active Line Based Blanking is enabled when the H_CONFIG bit is set LOW. In this mode,
the H output is HIGH for the entire horizontal blanking period, including the EAV and
SAV TRS words. This is the default H timing used by the device.
When H_CONFIG is set HIGH, TRS based blanking is enabled. In this case, the H output
will be HIGH for the entire horizontal blanking period as indicated by the H bit in the
received TRS ID words.
The timing of these signals is shown in Figure 4-3.
GS1559 HD-LINX™ II Multi-Rate Deserializer with
Loop-Through Cable Driver
Data Sheet
36 of 71
30572 - 8
July 2008
