Infrared Serial Communications Interface Module (IRSCI)
12.9.2 IRSCI Control Register 2
IRSCI control register 2:
•
Enables the following CPU interrupt requests:
–
–
–
–
Enables the SCTE bit to generate transmitter CPU interrupt requests
Enables the TC bit to generate transmitter CPU interrupt requests
Enables the SCRF bit to generate receiver CPU interrupt requests
Enables the IDLE bit to generate receiver CPU interrupt requests
•
•
•
•
Enables the transmitter
Enables the receiver
Enables SCI wakeup
Transmits SCI break characters
Address:
$0041
Bit 7
6
TCIE
0
5
SCRIE
0
4
ILIE
0
3
TE
0
2
RE
0
1
RWU
0
Bit 0
SBK
0
Read:
Write:
Reset:
SCTIE
0
Figure 12-13. IRSCI Control Register 2 (IRSCC2)
SCTIE — SCI Transmit Interrupt Enable Bit
This read/write bit enables the SCTE bit to generate SCI transmitter CPU interrupt requests. Reset
clears the SCTIE bit.
1 = SCTE enabled to generate CPU interrupt
0 = SCTE not enabled to generate CPU interrupt
TCIE — Transmission Complete Interrupt Enable Bit
This read/write bit enables the TC bit to generate SCI transmitter CPU interrupt requests. Reset clears
the TCIE bit.
1 = TC enabled to generate CPU interrupt requests
0 = TC not enabled to generate CPU interrupt requests
SCRIE — SCI Receive Interrupt Enable Bit
This read/write bit enables the SCRF bit to generate SCI receiver CPU interrupt requests. Reset clears
the SCRIE bit.
1 = SCRF enabled to generate CPU interrupt
0 = SCRF not enabled to generate CPU interrupt
ILIE — Idle Line Interrupt Enable Bit
This read/write bit enables the IDLE bit to generate SCI receiver CPU interrupt requests. Reset clears
the ILIE bit.
1 = IDLE enabled to generate CPU interrupt requests
0 = IDLE not enabled to generate CPU interrupt requests
TE — Transmitter Enable Bit
Setting this read/write bit begins the transmission by sending a preamble of 10 or 11 logic 1s from the
transmit shift register to the TxD pin. If software clears the TE bit, the transmitter completes any
transmission in progress before the TxD returns to the idle condition (logic 1). Clearing and then setting
TE during a transmission queues an idle character to be sent after the character currently being
transmitted. Reset clears the TE bit.
1 = Transmitter enabled
0 = Transmitter disabled
