External Memory Expansion Port (Port A)
BG1
BB
250
BG2
251
Figure 3-18 Asynchronous Bus Arbitration Timing
BG1
BG2
250+251
Figure 3-19 Asynchronous Bus Arbitration Timing
3.10.4 Background explanation for Asynchronous Bus Arbitration:
The asynchronous bus arbitration is enabled by internal synchronization circuits on BG and BB inputs.
These synchronization circuits add delay from the external signal until it is exposed to internal logic. As a
result of this delay, a 56300 part may assume mastership and assert BB for some time after BG is negated.
This is the reason for timing 250.
Once BB is asserted, there is a synchronization delay from BB assertion to the time this assertion is
exposed to other 56300 components which are potential masters on the same bus. If BG input is asserted
before that time, a situation of BG asserted, and BB negated, may cause another 56300 component to
assume mastership at the same time. Therefore some non-overlap period between one BG input active to
another BG input active is required. Timing 251 ensures that such a situation is avoided.
