Freescale Semiconductor, Inc.
MSCAN Controller
Identifier Acceptance Filter
ID28 IDR0 ID21 ID20 IDR1 ID15 ID14 IDR2
ID7 ID6 IDR3 RTR
ID10 IDR0
ID3 ID2
IDR1 IDE
AM7 CIDMRO AM0
AC7 CIDARO AC0
ID accepted (Filter 0 hit)
AM7 CIDMR1 AM0
AC7 CIDAR1 AC0
ID accepted (Filter 1 hit)
AM7 CIDMR2 AM0
AC7 CIDAR2 AC0
ID accepted (Filter 2 hit)
AM7 CIDMR3 AM0
AC7 CIDAR3 AC0
Figure 17-5. 8-bit Maskable Acceptance Filters
The identifier acceptance registers (CIDAR0–7) define the acceptable
patterns of the standard or extended identifier (ID10–ID0 or ID28–ID0).
Any of these bits can be marked don’t care in the identifier mask
registers (CIDMR0–7).
A filter hit is indicated to the application software by a set RXF (receive
buffer full flag, see msCAN12 Receiver Flag Register (CRFLG)) and
MC68HC912DG128 — Rev 3.0
Technical Data
MSCAN Controller
