1.5 Product Documentation
The documents in Table 1-2 are required for a complete description and proper design with the
56F8367/56F8167 devices. Documentation is available from local Freescale distributors, Freescale
semiconductor sales offices, Freescale Literature Distribution Centers, or online at
http://www.freescale.com.
Table 1-3 Chip Documentation
Topic
DSP56800E
Description
Order Number
Detailed description of the 56800E family architecture,
and 16-bit controller core processor and the instruction
set
DSP56800EERM
Reference Manual
56F8300 Peripheral User
Manual
Detailed description of peripherals of the 56F8300
devices
MC56F8300UM
MC56F83xxBLUM
MC56F8367
56F8300 SCI/CAN
Bootloader User Manual
Detailed description of the SCI/CAN Bootloaders
56F8300 family of devices
56F8367/56F8167
Technical Data Sheet
Electrical and timing specifications, pin descriptions,
and package descriptions (this document)
Errata
Details any chip issues that might be present
MC56F8367E
MC56F8167E
1.6 Data Sheet Conventions
This data sheet uses the following conventions:
OVERBAR
This is used to indicate a signal that is active when pulled low. For example, the RESET pin is
active when low.
“asserted”
“deasserted”
Examples:
A high true (active high) signal is high or a low true (active low) signal is low.
A high true (active high) signal is low or a low true (active low) signal is high.
Voltage1
Signal/Symbol
Logic State
True
Signal State
Asserted
PIN
PIN
PIN
PIN
VIL/VOL
False
Deasserted
Asserted
VIH/VOH
VIH/VOH
VIL/VOL
True
False
Deasserted
1. Values for VIL, VOL, VIH, and VOH are defined by individual product specifications.
56F8367 Technical Data, Rev. 9
14
Freescale Semiconductor
Preliminary
