1.5 Product Documentation
The documents listed in Table 1-1 are required for a complete description and proper design with the
56F8036. Documentation is available from local Freescale distributors, Freescale Semiconductor sales offices,
Freescale Literature Distribution Centers, or online at:
http://www.freescale.com
Table 1-1 56F8036 Chip Documentation
Topic
DSP56800E
Description
Order Number
DSP56800ERM
Detailed description of the 56800E family architecture,
16-bit Digital Signal Controller core processor, and the
instruction set
Reference Manual
56F802X and
56F803XPeripheral
Reference Manual
Detailed description of peripherals of the 56F802x and
56F803x family of devices
MC56F80xxRM
56F801xBLUG
56F802x and 56F803x
Serial Bootloader User
Guide
Detailed description of the Serial Bootloader in the
56F801x family of devices
56F8036
Technical Data Sheet
Electrical and timing specifications, pin descriptions,
and package descriptions (this document)
MC56F8036
56F8036
Errata
Details any chip issues that might be present
MC56F8036E
1.6 Data Sheet Conventions
This data sheet uses the following conventions:
OVERBAR
This is used to indicate a signal that is active when pulled low. For example, the RESET pin is
active when low.
“asserted”
“deasserted”
Examples:
A high true (active high) signal is high or a low true (active low) signal is low.
A high true (active high) signal is low or a low true (active low) signal is high.
Voltage1
Signal/Symbol
Logic State
True
Signal State
Asserted
PIN
PIN
PIN
PIN
VIL/VOL
False
Deasserted
Asserted
VIH/VOH
VIH/VOH
VIL/VOL
True
False
Deasserted
1. Values for V , V , V , and V are defined by individual product specifications.
IL
OL
IH
OH
56F8036 Data Sheet, Rev. 6
16
