10.2 DC Electrical Characteristics
Table 10-5 DC Electrical Characteristics
At Recommended Operating Conditions
Test
Conditions
Characteristic
Symbol
Notes
Min
Typ
Max
Unit
Output Voltage High
Output Voltage Low
VOH
VOL
IIH
Pin Group 1
Pin Groups 1, 2
Pin Groups 1, 2
2.4
—
—
—
0
—
0.4
V
V
IOH = IOHmax
IOL = IOLmax
Digital Input Current High (a)
pull-up enabled or disabled
—
+/- 2.5
μA
VIN = 2.4V
to 5.5V
Comparator Input Current High
Oscillator Input Current High
IIHC
IIHOSC
IIL
Pin Group 3
Pin Group 3
—
—
0
0
+/- 2
+/- 2
μA
μA
μA
VIN = VDDA
VIN = VDDA
VIN = 0V
Digital Input Current Low1
pull-up enabled
pull-up disabled
Pin Groups 1, 2
-15
—
-30
0
-60
+/- 2.5
Comparator Input Current Low
Oscillator Input Current Low
DAC Output Voltage Range
IILC
Pin Group 3
Pin Group 3
Internal
—
—
0
0
+/- 2
+/- 2
μA
μA
V
VIN = 0V
VIN = 0V
—
IILOSC
VDAC
Typically
—
Typically
VSSA
+
VDDA -
40mV
40mV
Output Current 1
High Impedance State
IOZ
Pin Groups 1, 2
Pin Groups 1, 2
—
0
+/- 2.5
μA
—
Schmitt Trigger Input Hysteresis
Input Capacitance
VHYS
CIN
—
—
—
0.35
10
—
—
—
V
—
—
—
pF
pF
Output Capacitance
COUT
10
1. See Figure 10-1
Default Mode
Pin Group 1: GPIO, TDI, TDO, TMS, TCK
Pin Group 2: RESET, GPIOA7
Pin Group 3: ADC and Comparator Analog Inputs
Pin Group 4: XTAL, EXTAL
56F8036 Data Sheet, Rev. 6
126
