Table 10-6 Current Consumption per Power Supply Pin (Continued)
Typical @ 3.3V, 25°C
Maximum@ 3.6V, 25°C
Mode
Conditions
1
1
IDDA
IDDA
IDD
IDD
STANDBY > STOP 100kHz Device Clock
Relaxation Oscillator in Standby mode
540μA
0μA
650μA
1μA
PLL powered off
Processor Core in STOP state
All peripheral module and core clocks are off
ADC/DAC/Comparator powered off
Voltage regulator in Standby mode
POWERDOWN
Device Clock is off
440μA
0μA
550μA
1μA
Relaxation Oscillator powered off
PLL powered off
Processor Core in STOP state
All peripheral module and core clocks are off
ADC /DAC/Comparator powered off
Voltage Regulator in Standby mode
1. No Output Switching
All ports configured as inputs
All inputs Low
No DC Loads
Table 10-7 Power-On Reset Low-Voltage Parameters
Typ
2.7
Max
—
Unit
Min
2.58
—
Characteristic
Symbol
VEI3.3
VE12.5
VEIH
Low-Voltage Interrupt for 3.3V supply1
V
V
Low-Voltage Interrupt for 2.5V supply2
2.15
50
—
Low-Voltage Interrupt Recovery Hysteresis
—
—
mV
V
Power-On Reset3
POR
—
1.8
1.9
1. When V drops below V
, an interrupt is generated.
DD
EI3.3
2. When V drops below V
, an interrupt is generated.
DD
EI32.5
3. Power-On Reset occurs whenever the internally regulated 2.5V digital supply drops below 1.8V. While
power is ramping up, this signal remains active for as long as the internal 2.5V is below 2.15V or the 3.3V
1/O voltage is below 2.7V, no matter how long the ramp-up rate is. The internally regulated voltage is
typically 100mV less than V during ramp-up until 2.5V is reached, at which time it self-regulates.
DD
10.2.1 Voltage Regulator Specifications
The 56F8036 has two on-chip regulators. One supplies the PLL and relaxation oscillator. It has no external
pins and therefore has no external characteristics which must be guaranteed (other than proper operation
of the device). The second regulator supplies approximately 2.5V to the 56F8036’s core logic. This
regulator requires an external 4.4µF, or greater, capacitor for proper operation. Ceramic and tantalum
56F8036 Data Sheet, Rev. 6
128
FreescaleSemiconductor
