DC Electrical Characteristics
Table 10-6 Current Consumption per Power Supply Pin (Typical)
Typical @ 3.3V, 25°C
Maximum@ 3.6V, 25°C
Mode
Conditions
1
1
IDDA
IDDA
IDD
IDD
RUN
32MHz Device Clock
42mA
13.5mA
—
—
Relaxation Oscillator on
PLL powered on
Continuous MAC instructions with fetches from
Program Flash
All peripheral modules enabled. TMR and PWM
using 1x Clock
ADC powered on and clocked
WAIT
STOP
32MHz Device Clock
Relaxation Oscillator on
PLL powered on
Processor Core in WAIT state
All Peripheral modules enabled. TMR and PWM
using 1x Clock
17mA
0μA
—
—
ADC powered off
4MHz Device Clock
Relaxation Oscillator on
PLL powered off
Processor Core in STOP state
All peripheral module and core clocks are off
ADC powered off
5mA
0μA
0μA
—
—
STANDBY > STOP 100KHz Device Clock
Relaxation Oscillator in Standby mode
430μA
550μA
1μA
PLL powered off
Processor Core in STOP state
All peripheral module and core clocks are off
ADC powered off
Voltage regulator in Standby mode
POWERDOWN
Device Clock is off
300μA
0μA
400μA
1μA
Relaxation Oscillator powered off
PLL powered off
Processor Core in STOP state
All peripheral module and core clocks are off
ADC powered off
Voltage Regulator in Standby mode
1. No Output Switching
All ports configured as inputs
All inputs Low
No DC Loads
56F8014 Technical Data, Rev. 9
Freescale Semiconductor
Preliminary
95
