Product Specifications
Operating Conditions
Ambient Operating Temperature
Absolute Maximum Ratings
Ambient Storage Temperature
–65°C to +150°C
–0.3V to 6.5V
FM24C04U/05U
FM24C04UE/05UE
FM24C04UV/05UV
0°C to +70°C
-40°C to +85°C
-40°C to +125°C
All Input or Output Voltages
with Respect to Ground
Lead Temperature
Positive Power Supply
FM24C04U/05U
(Soldering, 10 seconds)
+300°C
4.5V to 5.5V
2.7V to 5.5V
2.7V to 5.5V
ESD Rating
2000V min.
FM24C04UL/05UL
FM24C04ULZ/05ULZ
DC Electrical Characteristics (2.7V to 5.5V)
Symbol
Parameter
Test Conditions
Limits
Typ
Units
Max
Min
(Note 1)
ICCA
Active Power Supply Current fSCL = 400 KHz ("F" version)
fSCL = 100 KHz
0.2
1.0
mA
ISB
(Note 3)
Standby Current
VIN = GND VCC = 2.7V - 5.5V
10
1
0.1
50
10
1
µA
µA
µA
or VCC
VCC = 2.7V - 5.5V (L)
VCC = 2.7V - 4.5V (LZ)
ILI
ILO
Input Leakage Current
Output Leakage Current
Input Low Voltage
VIN = GND to VCC
0.1
0.1
1
1
µA
µA
V
VOUT = GND to VCC
VIL
VIH
VOL
–0.3
VCC x 0.3
VCC + 0.5
0.4
Input High Voltage
VCC x 0.7
V
Output Low Voltage
IOL = 3 mA
V
Capacitance TA = +25°C, f = 100/400 KHz, VCC = 5V (Note 2)
Symbol
CI/O
Test
Conditions
VI/O = 0V
Max Units
Input/Output Capacitance (SDA)
8
pF
CIN
Input Capacitance (A0, A1, A2, SCL)
VIN = 0V
6
pF
Note 1: Typical values are TA = 25°C and nominal supply voltage of 5V for 4.5V-5.5V operation and at 3V for 2.7V-4.5V operation.
Note 2: This parameter is periodically sampled and not 100% tested.
Note 3: The "L" and "LZ" versions can be operated in the 2.7V to 5.5V VCC range. However, for a standby current (ISB) of 1µA, the VCC should be within 2.7V to 4.5V.
