XRT86L30
REV. 1.0.1
SINGLE T1/E1/J1 FRAMER/LIU COMBO
TABLE 153: MICROPROCESSOR
REGISTER #566 BIT DESCRIPTION
R
EGISTER ADDRESS
C
HANNEL_0
R
EGISTER
YPE
R
VALUE
ESET
0
X
0F0A
H
FUNCTION
T
Bit #
D7
NAME
Reserved
R/W
R/W
0
0
D6-D0
B6S3_n -
B0S3_n
Arbitrary Transmit Pulse Shape, Segment 3
The shape of each channel's transmitted pulse can be made
independently user programmable by selecting “Arbitrary
Pulse” mode. The arbitrary pulse is divided into eight time
segments whose combined duration is equal to one period of
MCLK.
This 7 bit number represents the amplitude of the nth chan-
nel's arbitrary pulse during the third time segment. B6S3_n-
B0S3_n is in signed magnitude format with B6S3_n as the
sign bit and B0S3_n as the least significant bit (LSB).
TABLE 154: MICROPROCESSOR
R
EGISTER #567 BIT
D
ESCRIPTION
R
EGISTER
A
DDRESS
C
HANNEL_0
R
EGISTER
R
VALUE
ESET
0X0F0BH
FUNCTION
TYPE
Bit #
D7
NAME
Reserved
R/W
R/W
0
0
D6-D0
B6S4_n -
B0S4_n
Arbitrary Transmit Pulse Shape, Segment 4
The shape of each channel's transmitted pulse can be made
independently user programmable by selecting “Arbitrary
Pulse” mode. The arbitrary pulse is divided into eight time
segments whose combined duration is equal to one period of
MCLK.
This 7 bit number represents the amplitude of the nth chan-
nel's arbitrary pulse during the fourth time segment. B6S4_n-
B0S4_n is in signed magnitude format with B6S4_n as the
sign bit and B0S4_n as the least significant bit (LSB).
132
