A “Write-to- Buffer-Abort reset” command sequence is required when using the write buffer
Programming features in Unlock Bypass mode. Note that the Secured Silicon sector, autoselect, and
CFI functions are unavailable when a program operation is in progress.
Write buffer programming is allowed in any sequence of memory (or address) locations. These flash
devices are capable of handling multiple write buffer programming operations on the same write buffer
address range without intervening erases.
Use of the write buffer is strongly recommended for programming when multiple words are to be
programmed.
Figure 6. Write Buffer Programming Operation
