EM6603
Figure 12.Serial write buffer
Table 37.SWB buffer register - SWbuff
Bit
Name
Buff3
Buff2
Buff1
Buff0
Reset
R/W
R/W
R/W
R/W
R/W
Description
3
1
1
1
1
SWB buffer D3
SWB buffer D2
SWB buffer D1
SWB buffer D0
2
1
0
Table 38.SWB Low size register - LowSWB
Bit
Name
Reset
R/W
R/W
R/W
R/W
R/W
Description
3
Size[3]
Size[2]
Size[1]
Size[0]
0
0
0
0
Auto mode buffer size bit3
Auto mode buffer size bit2
Auto mode buffer size bit1
Auto mode buffer size bit0
2
1
0
Table 39.SWB High size register - HighSWB
Bit
Name
Reset
R/W
R/W
R/W
R/W
R/W
Description
3
AutoSWB
StSWB
Size[5]
Size[4]
0
0
0
0
SWB Automatic mode select
SWB start interactive mode
Auto mode buffer size bit5
Auto mode buffer size bit4
2
1
0
The SWB has two operational modes, automatic mode and interactive mode.
