EM78P258N
8-Bit Microprocessor with OTP ROM
6.2.9 IOCD0 (Pull-high Control Register)
7
6
5
4
3
2
1
0
/PH57
/PH56
/PH55
/PH54
/PH53
/PH52
/PH51
/PH50
NOTE
IOCD0 register is both readable and writable
Bit 7&Bit6:
Not used, fixed to “1”.
Bit 5 (/PH55): Control bit is used to enable the pull-high of the P55 pin.
0 = Enable internal pull-high;
1 = Disable internal pull-high.
Bit 4 (/PH54): Control bit is used to enable the pull-high of the P54 pin.
Bit 3 (/PH53): Control bit is used to enable the pull-high of the P53 pin.
Bit 2 (/PH52): Control bit is used to enable the pull-high of the P52 pin.
Bit 1 (/PH51): Control bit is used to enable the pull-high of the P51 pin.
Bit 0 (/PH50): Control bit is used to enable the pull-high of the P50 pin.
6.2.10 IOCE0 (WDT Control & Interrupt Mask Registers 2)
7
6
5
4
3
2
1
0
WDTE
EIS
ADIE
-
PSWE
PSW2
PSW1
PSW0
Bit 7 (WDTE): Control bit is used to enable Watchdog Timer
0 = Disable WDT
1 = Enable WDT
WDTE is both readable and writable
Bit 6 (EIS):
Control bit is used to define the function of the P60 (/INT) pin
0 = P60, bi-directional I/O pin
1 = /INT, external interrupt pin. In this case, the I/O control bit of P60
(Bit 0 of IOC60) must be set to "1"
NOTE
When EIS is "0," the path of /INT is masked. When EIS is "1," the status of /INT pin
can also be read by way of reading Port 6 (R6). Refer to Fig. 6-3 (I/O Port and I/O
Control Register Circuit for P60(/INT)) under Section 6.4 (I/O Ports).
EIS is both readable and writable.
Bit 5 (ADIE): ADIF interrupt enable bit
0 = disable ADIF interrupt
1 = enable ADIF interrupt
Bit 4:
Not used, fixed to “0”.
20 •
Product Specification (V1.0) 06.16.2005
(This specification is subject to change without further notice)
