DA14580
FINAL
Bluetooth Low Energy 4.2 SoC
5
Registers
This section contains a detailed view of the DA14580 registers. It is organized as follows: An overview table is pre-
sented initially, which depicts all register names, addresses and descriptions. A detailed bit level description of each
register follows.
The register file of the ARM Cortex-M0 can be found in the following documents, available on the ARM website:
Devices Generic User Guide:
DUI0497A_cortex_m0_r0p0_generic_ug.pdf
Technical Reference Manual:
DDI0432C_cortex_m0_r0p0_trm.pdf
These documents contain the register descriptions for the Nested Vectored Interrupt Controller (NVIC), the System
Control Block (SCB) and the System Timer (SysTick).
Datasheet
Revision 3.4
09-Nov-2016
CFR0011-120-01
18 of 155
© 2014 Dialog Semiconductor
