ELECTRICAL CHARACTERISTICS
DC CHARACTERISTICS
Table 6: DC Characteristics
Conditions: Ta = -55 to +125 ºC, Vdd = 3.3V ± 10% and 5V ± 10%
PARAMETER SYMBOL CONDITIONS
MIN
TYP
MAX
UNIT
ARINC INPUTS: RIN[1A/1B/2A/2B] aka DI[1A/1B/2A/2B] or
RIN[1A/1B/2A/2B]E aka DI[1A/1B/2A/2B]E with external 10K Ohm resistors
Differential Input Voltage
ONE
ZERO
NULL
Vil
Vil
Vnull
6.5
-13.0
-2.5
-10
10.0
-10.0
0
-13.0
-6.5
2.5
V
V
V
V
Common Mode Input Voltage
Input Resistance:
Differential
Vcm
10
RI
RG
RH
CI
24
12
12
132
67
7500
200
100
KOhm
KOhm
KOhm
pF
To GND
To VDD
Input Capacitance
20
LOGIC INPUTS
Vdd = 3.0V to 5.5V 0.7*Vdd
Input Voltage HI
Input Voltage LO
Input Pull-up Current,
/NFD. /RSR pins
VIH
VIL
IPU
Vdd+0.5
0.8
V
V
µA
Vdd = 3.0V to 5.5V
-0.5
-100
Input Currents, all others pins
IIN
-10
10
µA
LOGIC OUTPUTS
IOH = -4ma
IOH = -100ua
IOL = 4ma
Output Voltage: TTL Logic 1
Output Voltage: CMOS Logic 1
Output Voltage: TTL Logic 0
Output Voltage: CMOS Logic 0
Output Capacitance:
VOH-T
VOH-C
VOL-T
VOL-C
Cout
Vdd -0.5
Vdd -0.1
V
V
V
V
pF
0.4
0.1
10
IOL = 100ua
OPERATING SUPPLY CURRENT
VDD = 3.3V or 5V
Supply Voltage
IDD
Fck = 1MHZ
IDD ~
4*(VDD-2.7)
10
mA
V
VDD
3.0
5.5
