DS3251/DS3252/DS3253/DS3254
Register Name:
SRn
Register Description:
Register Address:
Status Register
03h, 13h, 23h, 33h
Bit
7
6
5
TDM
0
4
PRBS
0
3
2
1
RLOL
1
0
RLOS
1
Name
Default
—
—
—
—
—
—
—
—
Bit 5: Transmitter Driver Monitor (TDM). This read-only status bit indicates the current state of the transmit driver
monitor. See Section 9.6 for more information.
0 = the transmitter is operating normally
1 = the transmitter amplitude is out of range
Bit 4: PRBS Detector Output (PRBS). This read-only status bit indicates the current state of the receiver’s PRBS
detector. See Table 6-H for the expected PRBS pattern.
0 = in sync with expected pattern
1 = out of sync, expected pattern not detected
Bit 1: Receiver Loss of Lock (RLOL). This read-only status bit indicates the current state of the receiver clock
recovery PLL.
0 = the receiver PLL is locked onto the incoming signal
1 = the receiver PLL is not locked onto the incoming signal
Bit 0: Receiver Loss of Signal (RLOS). This read-only status bit indicates the current state of the receiver loss-of-
signal detector.
0 = signal present
1 = loss of signal
19 of 71
