CY7C9689
Pin Descriptions
(continued)
Pin
10
Name
RXFULL
I/O Characteristics
Signal Description
Three-state TTL out- Receive FIFO Full Flag.
put, changes following When the Receive FIFO is enabled (FIFOBYP is HIGH) and its flags are driven
RXCLK¦
(CE is LOW), RXFULL is asserted when space is available for four or fewer
characters to be written to the HOTLink Receive FIFO. If the RXCLK input is not
continuous or the FIFO is accessed at a rate slower than data is being received,
RXFULL may also indicate that some data has been lost because of FIFO
overflow.
When the Receive FIFO is bypassed (FIFOBYP is LOW), RXFULL is deassert-
ed to indicate that valid data may be present. RXFULL is also used as a BIST
progress indicator, and pulses once every pass through the 511 character BIST
loop.
When RXBISTEN is asserted (LOW), RXFULL becomes the receive BIST loop
progress indicator (regardless of the logic state of FIFOBYP). While RXBISTEN
is asserted, RXFULL is asserted until the receiver detects the start of the BIST
pattern. Then RXFULL is deasserted for the duration of the BIST pattern, puls-
ing asserted for one RXCLK period on the last symbol of each BIST loop. If 14
of 28 consecutive symbols are received in error, RXFULL returns to the asserted
state until the start of a BIST pattern is again detected.
The asserted state of this output (HIGH or LOW) is determined by the state of
the EXTFIFO input. When EXTFIFO is LOW, RXFULL is active LOW. When
EXTFIFO is HIGH, RXFULL is active HIGH.
19
RXHALF
Three-state TTL out- Receive FIFO Half-full Flag.
put, changes following When the Receive FIFO is enabled (FIFOBYP is HIGH and CE is LOW)
RXCLK¦
RXHALF is asserted when the HOTLink Receive FIFO is Š half full (128 char-
acters is half full). If a Receive FIFO reset has been initiated (RXRST was
sampled asserted for a minimum of seven RXCLK cycles), RXHALF is deas-
serted to enforce the empty/unavailable status of the Receive FIFO during reset.
If FIFOBYP is LOW, RXHALF remains deasserted having no logical function.
RXHALF is forced to the High-Z state only during a “full-chip” reset (i.e., while
RESET is LOW).
21
RXEMPTY
Three-state TTL out- Receive FIFO Empty Flag.
put, changes following When the Receive FIFO is enabled (FIFOBYP is HIGH) and its flags are driven
RXCLK¦
(CE is LOW), RXEMPTY is asserted when the HOTLink Receive FIFO has no
data to forward to the parallel interface. If a Receive FIFO reset has been initi-
ated (RXRST was sampled asserted for a minimum of seven RXCLK cycles),
RXEMPTY is asserted to enforce the empty/unavailable status of the Receive
FIFO during reset.
Any read operation occurring when RXEMPTY is asserted results in no change
in the FIFO status, and the data from the last valid read remains on the RXDATA
bus. When the Receive FIFO is bypassed but the decoder is enabled,
RXEMPTY is used as a valid data indicator. When deasserted it indicates that
valid data is present at the RXDATA or RXCMD outputs as indicated by RXSC/D.
When asserted it indicates that a SYNC character (JK or LM) is present on the
RXCMD output pins. When the Receive FIFO is bypassed (FIFOBYP is LOW),
RXEMPTY is deasserted whenever data is ready.
The asserted state of this output (HIGH or LOW) is determined by the state of
the EXTFIFO input. When EXTFIFO is LOW, RXEMPTY is active LOW. When
EXTFIFO is HIGH, RXEMPTY is active HIGH.
