MHV Single, Dual and Triple DC/DC Converters
28 VOLT INPUT – 15 WATT
SMD NUMBERS
MODEL NUMBERING KEY
STANDARD MICROCIRCUIT
MHV SERIES
MHV
28 512
T
F / 883
DRAWING (SMD)
SIMILAR PART
Base Model
Input Voltage
Output Voltage
5962-9852801HXC
5962-9852201HXC
5962-9852301HXC
5962-9852401HXC
5962-9852501HXC
5962-9852601HXC
5962-9852701HXC
5962-9673001HXC
5962-9673101HXC
MHV283R3S/883
MHV2805S/883
MHV2812S/883
MHV2815S/883
MHV2805D/883
MHV2812D/883
MHV2815D/883
MHV28512T/883
MHV28515T/883
(Main and aux. Vout for triple models)
(R = decimal point, 3R3 = 3.3 Vout)
Number of Outputs
(S = single, D = dual, T = triple)
Case Option
(Non-flanged case has no designator in
this position)
Screening
(Standard screening has no designator
in this position.)
Flanged SMD numbers for the MHV Series of converters have
the suffix HZC instead of HXC. For exact specifications for an
SMD product, refer to the SMD drawing available at
www.dscc.dla.mil/programs/smcr.
Model Selection
MHV28
Base model
Vout value
number of outputs
case option
screening
Choose one from each of the following rows
Vout value
for singles or duals: 3R3, 5, 12, or 15 for triples*: 512 or 515
“R” = decimal point, 3R3 = 3.3VDC
Number of outputs
Case option
Screening
S (single), D (dual) or T (triple)
non-flanged case option, leave blank F (flanged case option),
standard screening, leave blank
/ES (ES screening), /883 (Class H, QML)
* for triple models “5” indicates the main voltage, “12” or“15” indicate the auxiliary voltages.
