CX82100 Home Network Processor Data Sheet
9.3.18
GPIO Interrupt Polarity Control Register 2 for GPIO[31; 27:24; 22:16] (GPIO_IPC2:
0x003500F4)
GPIO_IPC2 is the interrupt polarity control register for GPIO[31; 27:24; 22:16].
Bit(s)
31:16;
31≥Y≥16,
Y = Bit #
Type
RO
Default
Name
Description
GPIO[X] Interrupt Polarity Mask, 31≥X≥16.
See specific GPIO_IPMSK{X},
bit
31≥X≥16,
Reading:
X = Y.
Return 0.
Writing:
0 = Mask off the function associated with GPIO_IP{X}.
1 = Enable the function associated with GPIO_IP{X}.
GPIO[X] Interrupt Polarity Control, 31≥X≥16.
Reading:
Return the last value written to bit #Y.
Writing:
15:0;
15≥Y≥0,
Y = Bit #
RW
See specific GPIO_IP{X},
bit
31≥X≥16,
X = Y+16.
1 = For GPIO_IPMSK{X} = 1, interrupt will occur upon GPIO[X]
high or positive edge; for GPIO_IPMSK{X} = 0, interrupt will
not occur upon GPIO[X] high or positive edge.
0 = For GPIO_IPMSK{X} = 1, interrupt will occur upon GPIO[X]
low or negative edge; for GPIO_IPMSK{X} = 0, interrupt will
not occur upon GPIO[X] low or negative edge.
Bit(s)
31
30:28
27
26
25
24
23
22
21
20
19
18
17
16
15
14:12
11
10
9
Type
RO
Default
1’b0
Name
GPIO_IPMSK31
Description
GPIO31 Interrupt Polarity Mask.
Reserved.
GPIO27 Interrupt Polarity Mask.
GPIO26 Interrupt Polarity Mask.
GPIO25 Interrupt Polarity Mask.
GPIO24 Interrupt Polarity Mask.
Reserved.
GPIO22 Interrupt Polarity Mask.
GPIO21 Interrupt Polarity Mask.
GPIO20 Interrupt Polarity Mask.
GPIO19 Interrupt Polarity Mask.
GPIO18 Interrupt Polarity Mask.
GPIO17 Interrupt Polarity Mask.
GPIO16 Interrupt Polarity Mask.
GPIO31 Interrupt Polarity Control.
Reserved.
GPIO27 Interrupt Polarity Control.
GPIO26 Interrupt Polarity Control.
GPIO25 Interrupt Polarity Control.
GPIO24 Interrupt Polarity Control.
Reserved.
RO
RO
RO
RO
1’b0
1’b0
1’b0
1’b0
GPIO_IPMSK27
GPIO_IPMSK26
GPIO_IPMSK25
GPIO_IPMSK24
RO
RO
RO
RO
RO
RO
RO
RW
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
GPIO_IPMSK22
GPIO_IPMSK21
GPIO_IPMSK20
GPIO_IPMSK19
GPIO_IPMSK18
GPIO_IPMSK17
GPIO_IPMSK16
GPIO_IP31
RW
RW
RW
RW
1’b0
1’b0
1’b0
1’b0
GPIO_IP27
GPIO_IP26
GPIO_IP25
GPIO_IP24
8
7
6
5
4
3
2
1
0
RW
RW
RW
RW
RW
RW
RW
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
1’b0
GPIO_IP22
GPIO_IP21
GPIO_IP20
GPIO_IP19
GPIO_IP18
GPIO_IP17
GPIO_IP16
GPIO22 Interrupt Polarity Control.
GPIO21 Interrupt Polarity Control.
GPIO20 Interrupt Polarity Control.
GPIO19 Interrupt Polarity Control.
GPIO18 Interrupt Polarity Control.
GPIO17 Interrupt Polarity Control.
GPIO16 Interrupt Polarity Control.
101306C
Conexant Proprietary and Confidential Information
9-17
