CX82100 Home Network Processor Data Sheet
9.3.19
GPIO Interrupt Polarity Control Register 3 for GPIO[39:37; 32] (GPIO_IPC3:
0x003500F8)
GPIO_IPC3 is the interrupt polarity control register for GPIO[39:37; 32].
Bit(s)
31:24
23:16;
23≥Y≥16,
Y = Bit #
Type
Default
Name
Description
Reserved.
RO
See specific GPIO_IPMSK{X},
GPIO[X] Interrupt Polarity Mask, 39≥X≥32.
bit
39≥X≥32,
X = Y+16.
Reading:
Return 0.
Writing:
0 = Mask off the function associated with GPIO_IP{X}.
1 = Enable the function associated with GPIO_IP{X}.
Reserved.
GPIO[X] Interrupt Polarity Control, 39≥X≥32.
Reading:
15:8
7:0;
7≥Y≥0,
Y = Bit #
RW
See specific GPIO_IP{X},
bit
39≥X≥32,
X = Y+32.
Return the last value written to bit #Y.
Writing:
1 = For GPIO_IPMSK{X} = 1, interrupt will occur upon GPIO[X]
high or positive edge; for GPIO_IPMSK{X} = 0, interrupt will
not occur upon GPIO[X] high or positive edge.
0 = For GPIO_IPMSK{X} = 1, interrupt will occur upon GPIO[X]
low or negative edge; for GPIO_IPMSK{X} = 0, interrupt will
not occur upon GPIO[X] low or negative edge.
Bit(s)
31:24
23
22
21
20:17
16
15:8
7
6
5
Type
Default
Name
Description
Reserved.
GPIO39 Interrupt Polarity Mask.
GPIO38 Interrupt Polarity Mask.
GPIO37 Interrupt Polarity Mask.
Reserved.
GPIO32 Interrupt Polarity Mask.
Reserved.
GPIO39 Interrupt Polarity Control.
GPIO38 Interrupt Polarity Control.
GPIO37 Interrupt Polarity Control.
Reserved.
RO
RO
RO
1’b0
1’b0
1’b0
GPIO_IPMSK39
GPIO_IPMSK38
GPIO_IPMSK37
RO
1’b0
GPIO_IPMSK32
RW
RW
RW
1’b0
1’b0
1’b0
GPIO_IP39
GPIO_IP38
GPIO_IP37
4:1
0
RW
1’b0
GPIO_IP32
GPIO32 Interrupt Polarity Control.
