Specification
Absolute Maximum Ratings
Exceeding the maximum rating can result in device damage. Operation of the device outside the operating limits is
not implied.
Supply voltage
-0.3 to 7.0V
Input voltage at any pin (ref VSS = 0V)
-0.3 to (VDD + 0.3V)
Sink/source current (supply pins)
(other pins)
+/- 30mA
+/- 20mA
Total device dissipation (DW/P) @ TAMB 25°C
(D5) @ TAMB 25°C
800mW Max.
550mW Max.
Derating
(DW/P)
(D5)
13mW/°C
9mW/°C
Operating temperature range: FX589DW/D5/P
-40°C to +85°C
Storage temperature range:
FX589DW/D5/P
-40°C to +85°C
Operating Limits
Correct operation of the device outside these limits is not implied.
Remarks
Min.
Max.
Unit
Supply Voltage (VDD)
Operating Temperature
Rx and Tx Data Rate
3.0
-40.0
4,000
4,000
1.0
5.5
+85.0
32,000
64,000
5.0
V
°C
(VDD ≥ 3.0V)
(VDD ≥ 4.5V) *Note 13
(VDD ≥ 3.0V)
bits/sec
bits/sec
MHz
MHz
ns
Xtal/Clock Frequency
(VDD ≥ 4.5V)
Note 10
1.0
40.0
10.3
“High” Pulse Width
“Low” Pulse Width
Note 10
40.0
ns
Operating Characteristics
All device characteristics are measured under the following conditions unless otherwise specified:
VDD = 5.0V, TAMB = 25°C. Xtal/Clock Frequency = 4.096MHz. Data Rate = 8,000 bits/sec.
Noise Bandwidth = Bit Rate.
Characteristics
See Note
Min.
Typ.
Max.
Unit
Static Values
Supply Current ((IDD) VDD = 3.0V) Tx PS Rx PS 1
1
0
1
0
1
1
0
0
-
-
-
-
0.5
1.0
1.0
1.5
-
-
-
-
mA
mA
mA
mA
((IDD) VDD = 5.0V)
1
0
1
0
1
1
0
0
-
-
-
-
1.0
2.0
3.0
4.0
-
-
-
-
mA
mA
mA
mA
Input Logic Levels
Logic “1”
3.5
-
-
-
-
-
-
-
V
V
Logic “0”
1.5
5.0
-
Logic Input Current
2
-5.0
4.6
-
µA
V
Logic “1” Output Level at IOH = -120µA
Logic “0” Output Level at IOL = 120µA
0.4
V
Transmit Parameters
Tx OUT, Output Impedance
Tx OUT, Level
3
4, 11
5
-
0.8
-
1.0
1.0
2.0
1.5
4.0
-
kΩ
1.2
2.5
2.0
-
V p-p
Tx Data Delay (BT = 0.3)
(BT = 0.5)
bit-periods
bit-periods
bit-periods
5
-
Tx PS to Output-Stable Time
6
-
14
