CS8900A
Crystal LAN™ Ethernet Controller
Reset value is: 0000 0000 0000 0000
4.3.6 DMA Frame Count
(Read only, Address: PacketPage base + 0028h)
Address 0029h
Address 0028h
Most significant byte of frame count
(most-significant nibble always 0h)
Least significant byte of frame count
The lower 12 bits of the DMA Frame Count register define the number of valid frames transferred via DMA since the
last readout of this register. The upper 4 bits are reserved. See Section 5.3 on page 90.
Reset value is: XXXX 0000 0000 0000
4.3.7 RxDMA Byte Count
(Read only, Address: PacketPage base + 002Ah)
Address 002Bh
Address 002Ah
Most significant byte of byte count
Least significant byte of byte count
The RxDMA Byte Count register describes the valid number of bytes DMAed since the last readout. See Section 5.3
on page 90.
Reset value is: 0000 0000 0000 0000
4.3.8 Memory Base Address
(Read/Write, Address: PacketPage base + 002Ch)
Address 002Fh
Reserved
Address 002Eh
Address 002Dh
Address 002Ch
The most significant nibble of
memory base address. The
high-order nibble is reserved.
Contains portion of memory
base address.
The least significant byte of
the memory base address.
Memory Base Address: The lower three bytes (002Ch, 002Dh, and 002Eh) are used for the 20-bit memory base
address. The upper three nibbles are reserved.
After reset, if no EEPROM is found by the CS8900A, then the register has the following initial state. If an EEPROM
is found, then the register's initial value may be set by the EEPROM. See Section 3.3 on page 19.
Reset value is: XXXX XXXX XXXX 0000 0000 0000 0000 0000
4.3.9 Boot PROM Base Address
(Read/Write, Address: PacketPage base + 0030h)
Address 0033h
Address 0032h
Address 0031h
Address 0030h
The most significant nibble of
Boot PROM base address. Contains portion of Boot PROM
The least significant byte of
the Boot PROM base
address.
Reserved
The high-order nibble is
reserved.
base address.
