to and from the host. The host simply writes to 0400h) and one transmit frame (starting at
and reads from these locations and internal PacketPage base + 0A00h) are directly acces-
buffer memory is dynamically allocated be-
tween transmit and receive as needed. This
provides more efficient use of buffer memory
and better overall network performance. As a
result of this dynamic allocation, only one re-
ceive frame (starting at PacketPage base +
sible. See Section 4.7 on page 72.
4.2 PacketPage Memory Map
Table 13 shows the CS8900A PacketPage
memory address map: s
PacketPage # of
Address Bytes
Type
Description
Cross Reference
Bus Interface Registers
0000h
0004h
0020h
4
28
2
Read-only Product Identification Code
Reserved
Section 4.3 on page 44
-
Note 2
Read/Write I/O Base Address
Section 4.3 on page 44,
Section 4.7 on page 72
0022h
0024h
0026h
0028h
002Ah
002Ch
0030h
0034h
2
2
2
2
2
4
4
4
Read/Write Interrupt Number (0,1,2,or 3)
Read/Write DMA Channel Number (0, 1, or 2)
Read-only DMA Start of Frame
Section 3.2 on page 18,
Section 4.3 on page 44
Section 3.2 on page 18,
Section 4.3 on page 44
Section 4.3 on page 44,
Section 5.3 on page 90
Read-only DMA Frame Count (12 Bits)
Read-only RxDMA Byte Count
Sections Section 4.3 on page 44,
”Receive DMA”
Section 4.3 on page 44,
Section 5.3 on page 90
Read/Write Memory Base Address Register
(20 Bit)
Section 4.3 on page 44,
Section 4.9 on page 73
Read/Write Boot PROM Base Address
Section 3.6 on page 26,
Section 4.3 on page 44
Read/Write Boot PROM Address Mask
Section 3.6 on page 26,
Section 4.3 on page 44
0038h
0040h
8
2
-
Reserved
Note 2
Read/Write EEPROM Command
Section 3.5 on page 25,
Section 4.3 on page 44
0042h
2
Read/Write EEPROM Data
Section 3.5 on page 25,
Section 4.3 on page 44
0044h
0050h
12
2
-
Reserved
Note 2
Read only Received Frame Byte Counter
Section 4.3 on page 44,
Section 5.2.9 on page 86
0052h
174
-
Reserved
Note 2
Status and Control Registers
Notes: 1. All registers are accessed as words only.
2. Read operation from the reserved location provides undefined data. Writing to a reserved location or
undefined bits may result in unpredictable operation of the CS8900A.
Table 13. PacketPage Memory Address Map
