CS5525 CS5526
SPECIFICATION DEFINITIONS
Linearity Error
The deviation of a code from a straight line which connects the two endpoints of the A/D
Converter transfer function. One endpoint is located 1/2 LSB below the first code transition
and the other endpoint is located 1/2 LSB beyond the code transition to all ones. Units in
percent of full-scale.
Differential Nonlinearity
The deviation of a code's width from the ideal width. Units in LSBs.
Full Scale Error
The deviation of the last code transition from the ideal [{(VREF+) - (VREF-)} - 3/2 LSB].
Units are in LSBs.
Unipolar Offset
The deviation of the first code transition from the ideal (1/2 LSB above the voltage on the
AIN- pin.). When in unipolar mode (U/B bit = 1). Units are in LSBs.
Bipolar Offset
The deviation of the mid-scale transition (111...111 to 000...000) from the ideal (1/2 LSB below
the voltage on the AIN- pin). When in bipolar mode (U/B bit = 0). Units are in LSBs.
ORDERING GUIDE
Model Number
CS5525-AP
CS5525-AS
CS5526-BP
CS5526-BS
Linearity Error (Max)
±0.003%
Temperature Range
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
Package
20-pin 0.3" Plastic DIP
20-pin 0.2" Plastic SSOP
20-pin 0.3" Plastic DIP
20-pin 0.2" Plastic SSOP
±0.003%
±0.0015%
±0.0015%
SPI™ is a trademark of Motorola Inc., Microwire™ is a trademark of National Semiconductor Corp.
