RECOMMENDED OPERATING CONDITIONS (DGND = 0V; all voltages with respect to ground)
Parameter
Symbol
Min
Typ
Max
Unit
DC Power Supplies:
Positive Digital
Positive Analog
Negative Analog
(VD+) - (VA+) (Note 3)
VD+
VA+
VA
-
4.75
4.75
-4.75
-0.3
5.0
5.0
-5.0
-
VA+
5.25
-5.25
0.0
V
V
V
V
Ambient Operating Temperature
TA
0
25
70
°C
Notes: 3. Applying power to VD+ prior to VA+ creates a SCR latch-up condition. Refer to Figure 2 for the
recommended power connections.
ABSOLUTE MAXIMUM RATINGS (AGND, DGND = 0V, all voltages with respect to ground.)
Parameter
Symbol
Min
Max
Unit
DC Power Supplies:
Positive Digital
Positive Analog
Negative Analog
VD+
VA+
VA-
-0.3
-0.3
0.3
(VA+)+ 0.3
6.0
V
V
V
-6.0
Input Current, Any Pin Except Supply
Digital Input Voltage
Iin
-
±10
(VA+) + 0.3
+125
mA
V
VIND
TA
-0.3
-55
-65
Ambient Operating Temperature (power applied)
Storage Temperature
°C
°C
TSTG
+150
4
DS82PP3
