SMPS Capacitors
Custom Lead Configurations
For the requirements that cannot be satisfied by standard
SMPS style products (SM0-style or SM9-style), AVX offers
leading edge solutions in custom lead configuration and
custom packaging. Custom lead configurations offering
optimum packaging, high current handling capabilities and
stress relief mounting options are all possible with AVX. The
custom solutions provided by AVX maintain high reliability of
stacked capacitor product originally developed by AVX and
historically recognized as the highest reliability product in the
market. Custom packaging options provide solutions that
eliminate reliability concerns in the next level assembly. These
custom options provide the following benefits:
• eliminate soldering requirements altogether by providing
means of electrical/mechanical connection to the circuit
• provide options for remote soldering away from large
ceramic capacitor body and eliminating the risk of thermal
shock (refer to photograph with soft, insulated leads
soldered to the stacked capacitor using high melting point
SN10 solder)
Many other innovations are available from AVX Olean
Advanced Products. Let them apply these ideas to your
application specific requirements. Please consult with AVX’s
Application Engineering staff for a custom solution that will
meet demands of your program requirements.
CUSTOM LEAD
CONFIGURATIONS…
CUSTOM PACKAGING…
