MH Ceramic Capacitor
Lead Free Ceramic Capacitor in Molded SM Leadframe
AVX are pleased to introduce the MH range of multi layer ceramic capacitors. The MH components
are surface mount molded parts with a multi layer ceramic insert.
MH capacitors combine the ceramic attributes of very low ESR, non polar construction, excellent
high frequency behavior, excellent voltage stress capabilities and wide temperature range; with the
enhanced mechanical protection of a molded case.
The MH range provides a lead free solution to customers who have previously been unable to use
large case ceramic capacitors because of mechanical stressing concerns.
HOW TO ORDER
MH
V
1
1
C
225
M
A
T
2
A
MH Series
Case
Size
see table
below
MLCC Voltage Dielectric Capacitance Capacitance
Failure
Rate
A = Not
Applicable
Terminations Packaging Special
3 = 25V
5 = 50V
1 = 100V
Tolerance
K = 10ꢀ
M = 20ꢀ
2 = 7" Reel
4 = 13" Reel
6 = Waffle
Pack
Code
A =
Count
C = X7R
Code (In pF)
2 Sig. Digits
+ Number of
Zeros
T = Tin Plated
Std.
Product
MH X7R TARGET RANGE
PACKAGING
7" Reels
400
1500
108
Cap μF
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
25V
50V
100V
13" Reels
Waffle Pack
105
125
155
185
225
275
335
395
475
565
685
825
106
126
156
186
226
276
336
396
476
CASE DIMENSIONS: millimeters (inches)
EIA
Code
W+0.20 (0.008) H+0.20 (0.008)
Code
L 0.20 (0.008)
-0.10 (0.004)
-0.10 (0.004)
3.45 0.30
(0.136 0.012)
V
7361-38
7.30 (0.287)
6.10 (0.240)
12
15
18
22
27
33
39
47
= In development, contact plant for detail
NOTICE: Specifications are subject to change without notice. Contact your nearest AVX Sales Office for the latest specifications. All
statements, information and data given herein are believed to be accurate and reliable, but are presented without guarantee,
warranty, or responsibility of any kind, expressed or implied. Statements or suggestions concerning possible use of our products
are made without representation or warranty that any such use is free of patent infringement and are not recommendations to
infringe any patent. The user should not assume that all safety measures are indicated or that other measures may not be required.
Specifications are typical and may not apply to all applications.
LEAD-FREE COMPATIBLE
COMPONENT
TS 16949, ISO 14001
Certified Manufacture
42
