26. Electrical Characteristics
26.1 Absolute Maximum Ratings*
*NOTICE:
Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Operating Temperature.................................. -55°C to +125°C
Storage Temperature..................................... -65°C to +150°C
Voltage on any Pin except RESET & UVcc
with respect to Ground(7) .............................-0.5V to VCC+0.5V
Voltage on RESET with respect to Ground......-0.5V to +13.0V
Voltage on UVcc with respect to Ground...........-0.5V to +6.0V
Maximum Operating Voltage ............................................ 6.0V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current VCC and GND Pins................................ 200.0 mA
26.2 DC Characteristics
TA = -40°C to 85°C, VCC = 2.7V to 5.5V (unless otherwise noted)
Symbol
Parameter
Condition
Min.(5)
Typ.
Max.(5)
Units
Input Low Voltage,
Standard IOs(8)
(1)
VIL
VCC = 2.7V - 5.5V
-0.5
0.2VCC
0.1VCC
0.1VCC
0.8
V
Input Low Voltage,
XTAL1 pin
(1)
(1)
VIL1
VIL2
VIL3
VIL4
VIH
VCC = 2.7V - 5.5V
-0.5
-0.5
-0.5
-0.5
V
V
V
V
V
V
V
V
V
Input Low Voltage,
RESET pin
VCC = 2.7V - 5.5V
Input Low Voltage,
MOSI/MISO pins
VCC = 2.7V - 5.5V
VCC = 4.5V - 5.5V
VCC = 2.7V - 5.5V
VCC = 2.7V - 5.5V
VCC = 2.7V - 5.5V
Input Low Voltage, PS2
pins
0.7
Input High Voltage,
Standard IOs(8)
(2)
0.6VCC
0.7VCC
0.9VCC
2
VCC + 0.5
VCC + 0.5
VCC + 0.5
VCC + 0.5
VCC + 0.5
Input High Voltage,
XTAL1 pin
(2)
(2)
VIH1
VIH2
VIH3
VIH4
Input High Voltage,
RESET pin
Input High Voltage,
MOSI/MISO pins
VCC = 2.7V - 5.5V
Input High Voltage, PS2
pins
VCC = 4.5V - 5.5V
2.4
Output Low Voltage(3),
Standard IOs(8),
MOSI/MISO pins
IOL = 10mA, VCC = 5V
IOL = 5mA, VCC = 3V
0.7
0.5
VOL
V
262
