22.4 Endpoint reset
An endpoint can be reset at any time by setting in the UERST register the bit corresponding to
the endpoint (EPRSTx). This resets:
• the internal state machine on that endpoint,
• the Rx and Tx banks are cleared and their internal pointers are restored,
• the UEINTX, UESTA0X and UESTA1X are restored to their reset value.
The data toggle field remains unchanged.
The other registers remain unchanged.
The endpoint configuration remains active and the endpoint is still enabled.
The endpoint reset may be associated with a clear of the data toggle command (RSTDT bit) as
an answer to the CLEAR_FEATURE USB command.
22.5 USB reset
When an USB reset is detected on the USB line, the next operations are performed by the
controller:
• all the endpoints are disabled, except the default control endpoint,
• the default control endpoint is reset (see Section 22.4, page 270 for more details).
• The data toggle of the default control endpoint is cleared.
22.6 Endpoint selection
Prior to any operation performed by the CPU, the endpoint must first be selected. This is done
by:
• Clearing EPNUMS.
• Setting EPNUM with the endpoint number which will be managed by the CPU.
The CPU can then access to the various endpoint registers and data.
22.7 Endpoint activation
The endpoint is maintained under reset as long as the EPEN bit is not set.
The following flow must be respected in order to activate an endpoint:
