EMI Backshells
Series MBS
Amphenol
Aerospace
Suitaꢈle ꢇor M83513 Connectors
Connector shown
for reference
(order separately)
NO HARDWARE SHOWN
WITH HARDWARE SHOWN
CONNECTOR
MATING FACE
D
A
MAX
B
C
D
SIZE
.005 (0.13)
.005 (0.13)
.020 (0.51)
09
15
21
25
31
37
51
100
.785 (19.94)
.935 (23.75)
1.085 (27.56)
1.185 (30.10)
1.335 (33.91)
1.485 (37.72)
1.435 (36.45)
2.175 (55.25)
.565 (14.35)
.715 (18.16)
.865 (21.97)
.965 (24.51)
1.115 (28.32)
1.265 (32.13)
1.215 (30.86)
1.800 (45.72)
.340 (8.64)
.340 (8.64)
.340 (8.64)
.340 (8.64)
.340 (8.64)
.340 (8.64)
.400 (10.16)
.450 (11.43)
.762 (19.35)
.812 (20.62)
.862 (21.89)
.912 (23.16)
.952 (24.18)
.992 (25.20)
1.072 (27.32)
1.137 (28.88)
A
RIBBED FOR TIE WRAP FEATURE
MBS BACKSHELL
B
L
W
C
R1
R2
W
L
R1
R2
SIZE
AVAILABLE ON SIZE
.010 (0.25)
.010 (0.25)
.010 (0.25)
.020 (0.51)
A
B
C
D
E
.290 (7.37)
.290 (7.37)
.290 (7.37)
.304 (7.72)
.304 (7.72)
.304 (7.72)
.304 (7.72)
.384 (9.75)
.344 (8.74)
.494 (12.55)
.644 (16.36)
.744 (18.90)
.894 (22.71)
.994 (25.25)
1.044 (26.52)
1.524 (38.71)
.109 (2.77)
.109 (2.77)
.109 (2.77)
.109 (2.77)
.109 (2.77)
.109 (2.77)
.109 (2.77)
.125 (3.18)
.182 (4.62)
.353 (8.97)
09 THRU 100
15 THRU 100
21 THRU 100
25 THRU 100
31 THRU 100
37 THRU 100
37 AND 100
100 ONLY
.757 (19.23)
.940 (23.88)
1.488 (37.80)
1.893 (48.08)
2.128 (54.05)
3.187 (80.95)
F
G
H
Inches (mm)
All dimensions for reference only
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
