ABSOLUTE MAXIMUM RATINGS
OPERATING RANGES
Storage Temperature: . . . . . . . . . . . . –65 to +150°C
Ambient Temperature Under Bias: . . . –65 to +125°C
Commercial (C) Devices
Temperature (TA) . . . . . . . . . . . . . . . . . 0°C to + 70°C
Supply Voltage to AVSS
or DVSS (AVDD, DVDD): . . . . . . . . . . . . . . –0.3 to +6 V
Supply Voltages (VCC, VDDT, VDDU1, VDDU2, VDDM, VDDP)
. . . . . . . . . . . . . . . . . . . . +5 V ± 5% or 3.0 V to 3.6 V
Supply Voltages
(AVDD, VDD5) . . . . . . . . . . . . . . . . . . . . . . . . +5 V ± 5%
Stresses above those listed under Absolute Maximum
Ratings may cause permanent device failure. Functionality at
or above these limits is not implied. Exposure to Absolute
Maximum Ratings for extended periods may affect
device reliability.
Operating ranges define those limits between which the func-
tionality of the device is guaranteed.
IEEE 1149.1 DC CHARACTERISTICS (5.0 and 3.3 V)
Parameter
Symbol
Parameter Description
TCK, TMS, TDI, TRST
TCK, TMS, TDI, TRST
TDO
Test Conditions
Min
2.0
2.4
Max
Units
V
VIL
0.8
VIH
V
VOL
VOH
IIL
IOL = 2.0 mA
0.4
V
TDO
IOH = –0.4 mA
V
TCK, TRST
TCK, TRST
TMS, TDI
VDD = 5.5 V, VI = 0.5 V
VDD = 5.5 V, VI = 2.7 V
VDD = 5.5 V, VI = 0.5 V
VDD = 5.5 V, VI = 2.7 V
VOUT = 0.4 V
–400
–200
–400
–200
µA
µA
µA
µA
µA
µA
IIH
IIL
IIH
TMS, TDI
IOZL
IOZH
TDO
–10
TDO
VOUT = VDD
+10
130
Am79C930
