DC & Switching Characteristics
However, when the output is a double data rate input/output (DDIO)
signal, both edges of the input clock signal (positive and negative) trigger
output transitions (Figure 5–9). Therefore, any distortion on the input
clock and the input clock buffer affect the output DCD.
Figure 5–9. DCD Measurement Technique for DDIO (Double-Data Rate) Outputs
IOE
V
CC DFF
D
PRN
Q
INPUT
VCC
clk
CLRN
inst2
OUTPUT
output
DFF
D
PRN
Q
GND
NOT
inst8
CLRN
inst3
When an FPGA PLL generates the internal clock, the PLL output clocks
the IOE block. As the PLL only monitors the positive edge of the reference
clock input and internally re-creates the output clock signal, any DCD
present on the reference clock is filtered out. Therefore, the DCD for a
DDIO output with PLL in the clock path is better than the DCD for a
DDIO output without PLL in the clock path.
Tables 5–80 through 5–87 give the maximum DCD in absolution
derivation for different I/O standards on Stratix II devices. Examples are
also provided that show how to calculate DCD as a percentage.
Table 5–80. Maximum DCD for Non-DDIO Output on Row I/O Pins (Part 1
of 2)
Note (1)
Maximum DCD for Non-DDIO Output
Row I/O Output
Standard
-3 Devices
-4 & -5 Devices
Unit
3.3-V LVTTTL
3.3-V LVCMOS
2.5 V
245
125
105
275
155
135
ps
ps
ps
