September 2005
ASM5P2304B
rev 0.5
Operating Conditions for ASM5I2304B Industrial Temperature Devices
Parameter
Description
Min
3.0
Max
3.6
85
Unit
V
VDD
TA
Supply Voltage
Operating Temperature (Ambient Temperature)
Load Capacitance, from 4MHz to 20MHz
Input Capacitance6
-40
°C
CL
30
pF
pF
CIN
7
Note:
6. Applies to both Ref Clock and FBK.
Electrical Characteristics for ASM5I2304B Industrial Temperature Devices
Parameter
Description
Input LOW Voltage
Input HIGH Voltage
Input LOW Current
Input HIGH Current
Test Conditions
Min
Max
0.8
Unit
V
VIL
VIH
IIL
2.0
V
VIN = 0V
50.0
µA
µA
IIH
VIN = VDD
100.0
I
I
OL = 8mA (-1, -2)
VOL
VOH
Output LOW Voltage7
0.4
V
V
OH = 12mA (-1H, -2H)
I
I
OL = -8mA (-1, -2)
OH = -12mA (-1H, -2H)
Output HIGH Voltage7
2.4
Unloaded outputs, 20MHz REF
(-1, -1H, -2, -2H)
IDD
Supply Current
10
mA
Note:
7. Parameter is guaranteed by design and characterization. Not 100% tested in production.
3.3V Zero Delay Buffer
6 of 13
