September 2005
ASM5P23S08A
rev 1.4
Switching Characteristics for ASM5P23S08A Commercial Temperature Devices
Parameter
Description
Output Frequency
Test Conditions
Min
Typ
Max
Unit
1/t1
1/t1
1/t1
30pF load, All devices
15
15
15
100
133
133
MHz
MHz
MHz
Output Frequency
Output Frequency
15pF load, -5H devices 8
15pF load, -2, -3, -4 devices
Duty Cycle 9 = (t2 / t1) * 100
(-1, -2, -3, -4, -1H, -5H)
Measured at 1.4V, FOUT = <66.66MHz 30pF load
Measured at 1.4V, FOUT = <50MHz 15pF load
40.0
45.0
50.0
50.0
60.0
55.0
%
%
Duty Cycle9 = (t2 / t1) * 100
(-1, -2, -3, -4, -1H, -5H)
t3
t3
t3
t4
t4
t4
Output Rise Time 9 ( -2, -3, -4)
Output Rise Time 9 ( -2, -3, -4)
Output Rise Time 9 ( -5H)
Measured between 0.8V and 2.0V 30pF load
Measured between 0.8V and 2.0V 15pF load
Measured between 0.8V and 2.0V 30pF load
Measured between 2.0V and 0.8V 30pF load
Measured between 0.8V and 2.0V 15pF load
Measured between 2.0V and 0.8V 30pF load
2.20
1.50
1.50
2.20
1.50
1.25
nS
nS
nS
nS
nS
nS
Output Fall Time 9 ( -2, -3, -4)
Output Fall Time 9 ( -2, -3, -4)
Output Fall Time 9 ( -5H)
Output-to-output skew on same
bank ( -2, -3, -4) 9
All outputs equally loaded
All outputs equally loaded
All outputs equally loaded
200
200
200
Output-to-output skew ( -5H)
t5
pS
Output bank A -to- output
bank B skew ( -4, -5H)
Output bank A -to- output
bank B skew (-2, -3)
All outputs equally loaded
Measured at VDD /2
400
Delay, REF Rising Edge to FBK
Rising Edge 9
t6
t7
0
0
±250
pS
pS
Device-to-Device Skew 9
Measured at VDD/2 on the FBK pins of the device
Measured at 66.67MHz, loaded outputs, 15pF load
Measured at 66.67MHz, loaded outputs, 30pF load
Measured at 133MHz, loaded outputs, 15pF load
Measured at 66.67MHz, loaded outputs, 30pF load
Measured at 66.67MHz, loaded outputs, 15pF load
700
200
200
100
400
400
Cycle-to-cycle jitter 9
( -4, -5H)
tJ
pS
tJ
Cycle-to-cycle jitter 9 (-2, -3)
PLL Lock Time 9
pS
Stable power supply, valid clock presented on REF
& FBK pins
tLOCK
1.0
mS
Note: 9. Parameter is guaranteed by design and characterization. Not 100% tested in production.
3.3V ‘SpreadTrak’ Zero Delay Buffer
7 of 18
Notice: The information in this document is subject to change without notice.
