[AK4679]
MSBSB BCKPB
Data Interface Format
Figure
bit
bit
MSB of SDTOB is output by the rising edge (“↑”) of SYNCB. MSB of SDTIB is latched
by the falling edge (“↓”) of the BICKB just after the output timing of SDTOB’s MSB.
MSB of SDTOB is output by the rising edge (“↑”) of SYNCB. MSB of SDTIB is latched
by the rising edge (“↑”) of the BICKB just after the output timing of SDTOB’s MSB.
MSB of SDTOB is output by the rising edge (“↑”) of the first BICKB after the rising edge
0
0
Figure 100
Figure 101
0
1
1
0
(“↑”) of SYNCB. MSB of SDTIB is latched by the falling edge (“↓”) of the BICKB just Figure 102
after the output timing of SDTOB’s MSB.
MSB of SDTOB is output by the falling edge (“↓”) of the first BICKB after the rising
edge (“↑”) of SYNCB. MSB of SDTIB is latched by the rising edge (“↑”) of the BICKB Figure 103
just after the output timing of SDTOB’s MSB.
1
1
Table 122. PCM I/F B Format in Mode 1
MS1402-E-06
2013/02
