LOUT
ROUT
1μF
220Ω
20kΩ
Figure 78. External Circuit for Stereo Line Output (in case of using Pop Noise Reduction Circuit)
<Stereo Line Output Control Sequence (in case of using Pop Noise Reduction Circuit)>
(2 )
(5 )
P M L O b it
P M R O b it
(1)
(3 )
(4 )
(6 )
L O P S bit
L O U T p in
R O U T p in
N o rm a l O utp u t
≥ 3 0 0 m s
≥ 3 0 0 m s
Figure 79. Stereo Line Output Control Sequence (in case of using Pop Noise Reduction Circuit)
(1) Set LOPS bit = “1”. Stereo line output enters power-save mode.
(2) Set PMLO=PMRO bits = “1”. Stereo line output exits power-down mode.
LOUT and ROUT pins rise up to common voltage (typ. 0.8 x AVDD). Rise time is 200ms (max 300ms) at
C=1μF and AVDD=1.8V.
(3) Set LOPS bit = “0” after LOUT and ROUT pins rise up. Stereo line output exits power-save mode.
Stereo line output is enabled.
(4) Set LOPS bit = “1”. Stereo line output enters power-save mode.
(5) Set PMLO=PMRO bits = “0”. Stereo line output enters power-down mode.
LOUT and ROUT pins fall down to VSS1. Fall time is 200ms (max 300ms) at C=1μF and AVDD=1.8V.
(6) Set LOPS bit = “0” after LOUT and ROUT pins fall down. Stereo line output exits power-save mode.
