Latency
Tc = 25°C, VCC = 4.5 V to 5.5 V
Latency
(Clock
Cycles)
Latency Definition
Tx
Rx
1
2
3
Delay measured from the rising edge of STRBIN to the first bit D0 in the serial
stream
Delay measured from the input of the data frame to the falling edge of STRBOUT
when the data frame is updated
Delay measured from the rising edge of the Tx STRBIN when the data frame is read
to the falling edge of the Rx STRBOUT when the data frame is updated
Link
HDMP-1022 (Tx), HDMP-1024 (Rx)
Absolute Maximum Ratings
TA = 25°C, except as specified. Operation in excess of any one of these conditions may result in permanent
damage to this device.
Symbol
VCC
VIN,TTL
Parameter
Units
V
V
V
mA
°C
Min.
-0.5
-0.7
Max.
7.0
VCC + 0.5
Supply Voltage
TTL Input Voltage
H50 Input Voltage
V
IN,BLL
VCC - 2.0 VCC + 0.5
+13
IO,TTL
Tstg
TJ
TTL Output Source Current
Storage Temperature
Junction Temperature
-40
-40
+130
+130
+260
°C
°C
Tmax
Maximum Assembly Temperature (for 10 seconds maximum)
627
