Absolute Maximum Ratings
Storage Temperature .................................................. -55°C to +125°C
Operating Temperature (TA)........................................ -55°C to +100°C
Junction Temperature (TJ) ............................................................125°C
Reflow Temperature Profile ... See Package Outline Drawings Section
Lead Solder Temperature ..................................................260°C for 10s
(up to seating plane)
Average Input Current - IF ............................................................ 25 mA
Peak Input Current - IF ................................................................. 40 mA
(50 ns maximum pulse width)
Reverse Input Voltage - VR .............................................................. 2.5 V
(IR = 100 µA, Pin 1-2)
Input Power Dissipation ......................................... 60 mW @ TA = 85°C
(Derate at 2.2 mW/°C for operating temperatures above 85°C)
Reverse Output Photodiode Voltage ................................................ 30 V
(Pin 6-5)
Reverse Input Photodiode Voltage................................................... 30 V
(Pin 3-4)
Recommended Operating Conditions
Storage Temperature .................................................... -40°C to +85°C
Operating Temperature................................................. -40°C to +85°C
Average Input Current - IF ....................................................... 1 - 20 mA
Peak Input Current - IF ................................................................. 35 mA
(50% duty cycle, 1 ms pulse width)
Reverse Output Photodiode Voltage ........................................... 0 - 15 V
(Pin 6-5)
Reverse Input Photodiode Voltage.............................................. 0 - 15 V
(Pin 3-4)
1-422
