ADV7180
Table 67.VBI Data Standards to be Decoded on Line Px (PAL) or Line Ny (NTSC)
Signal Name
Register Location
VDP_LINE_00F[7:4]
VDP_LINE_010[7:4]
VDP_LINE_011[7:4]
VDP_LINE_012[7:4]
VDP_LINE_013[7:4]
VDP_LINE_014[7:4]
VDP_LINE_015[7:4]
VDP_LINE_016[7:4]
VDP_LINE_017[7:4]
VDP_LINE_018[7:4]
VDP_LINE_019[7:4]
VDP_LINE_01A[7:4]
VDP_LINE_01B[7:4]
VDP_LINE_01C[7:4]
VDP_LINE_01D[7:4]
VDP_LINE_01E[7:4]
VDP_LINE_01F[7:4]
VDP_LINE_020[7:4]
VDP_LINE_021[7:4]
VDP_LINE_00E[3:0]
VDP_LINE_00F[3:0]
VDP_LINE_010[3:0]
VDP_LINE_011[3:0]
VDP_LINE_012[3:0]
VDP_LINE_013[3:0]
VDP_LINE_014[3:0]
VDP_LINE_015[3:0]
VDP_LINE_016[3:0]
VDP_LINE_017[3:0]
VDP_LINE_018[3:0]
VDP_LINE_019[3:0]
VDP_LINE_01A[3:0]
VDP_LINE_01B[3:0]
VDP_LINE_01C[3:0]
VDP_LINE_01D[3:0]
VDP_LINE_01E[3:0]
VDP_LINE_01F[3:0]
VDP_LINE_020[3:0]
VDP_LINE_021[3:0]
Dec Address
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
Hex Address
0x65
0x66
0x67
0x68
0x69
0x6A
0x6B
0x6C
0x6D
0x6E
0x6F
0x70
0x71
0x72
0x73
0x74
0x75
0x76
0x77
0x64
0x65
0x66
0x67
0x68
0x69
0x6A
0x6B
0x6C
0x6D
0x6E
0x6F
0x70
0x71
0x72
0x73
0x74
0x75
0x76
0x77
VBI_DATA_P6_N23
VBI_DATA_P7_N24
VBI_DATA_P8_N25
VBI_DATA_P9
VBI_DATA_P10
VBI_DATA_P11
VBI_DATA_P12_N10
VBI_DATA_P13_N11
VBI_DATA_P14_N12
VBI_DATA_P15_N13
VBI_DATA_P16_N14
VBI_DATA_P17_N15
VBI_DATA_P18_N16
VBI_DATA_P19_N17
VBI_DATA_P20_N18
VBI_DATA_P21_N19
VBI_DATA_P22_N20
VBI_DATA_P23_N21
VBI_DATA_P24_N22
VBI_DATA_P318
VBI_DATA_P319_N286
VBI_DATA_P320_N287
VBI_DATA_P321_N288
VBI_DATA_P322
VBI_DATA_P323
VBI_DATA_P324_N272
VBI_DATA_P325_N273
VBI_DATA_P326_N274
VBI_DATA_P327_N275
VBI_DATA_P328_N276
VBI_DATA_P329_N277
VBI_DATA_P330_N278
VBI_DATA_P331_N279
VBI_DATA_P332_N280
VBI_DATA_P333_N281
VBI_DATA_P334_N282
VBI_DATA_P335_N283
VBI_DATA_P336_N284
VBI_DATA_P337_N285
Note that full field detection (lines other than VBI lines) of any standard can also be enabled by writing into the registers
VBI_DATA_P24_N22[3:0] and VBI_DATA_P337_N285[3:0]. So, if VBI_DATA_P24_N22[3:0] is programmed with any teletext
standard, then teletext is decoded off for the entire odd field. The corresponding register for the even field is VBI_DATA_P337_N285[3:0].
For teletext system identification, VDP assumes that if teletext is present in a video channel, all the teletext lines comply with a single
standard system. Thus, the line programming using VBI_DATA_Px_Ny registers identifies whether the data in line is teletext; the actual
standard is identified by the VDP_TTXT_TYPE_MAN bit. To program the VDP_TTXT_TYPE_MAN bit, the
VDP_TTXT_TYPE_MAN_ENABLE bit must be set to 1.
Rev. A | Page 52 of 112
