Mode 1 CVBS Input (Composite Video on A
IN
1)
All standards are supported through autodetect, 8-bit, 4:2:2, ITU-R BT.656 output on P0 to P7
Table 108. Mode 1 CVBS Input
Register Address (Hex)
00
04
17
31
3D
3E
3F
0E
55
0E
Register Value (Hex)
00
57
41
02
A2
6A
A0
80
81
00
Notes
INSEL = CVBS in on A
IN
1
Enable SFL
Select SH1
Clear NEWAV_MODE, SAV/EAV to suit ADV video encoders
MWE enable manual window, color kill threshold to 2
BLM optimization
BGB optimization
Hidden space
ADC configuration
User space
Mode 2 S-Video Input (Y on A
IN
1 and C on A
IN
2)
All standards are supported through autodetect, 8-bit, ITU-R BT.656 output on P0 to P7.
Table 109. Mode 2 S-Video Input
Register Address (Hex)
00
04
31
3D
3E
3F
58
0E
55
0E
Register Value (Hex)
06
57
02
A2
6A
A0
04
80
81
00
Notes
Insel = Y/C, Y = A
IN
1, C = A
IN
2
Enable SFL
Clear NEWAV_MODE, SAV/EAV to suit ADV video encoders
MWE enable manual window, color kill threshold to 2
BLM optimization
BGB optimization
Mandatory write. This must be performed for correct operation.
Hidden space
ADC configuration
User space
Mode 3 525i/625i YPrPb Input (Y on A
IN
1, Pb on A
IN
2, and Pr on A
IN
3)
All standards are supported through autodetect, 8-bit, ITU-R BT.656 output on P0 to P7.
Table 110. Mode 3 YPrPb Input
Register Address (Hex)
00
31
3D
3E
3F
0E
55
0E
Register Value (Hex)
09
02
A2
6A
A0
80
81
00
Notes
INSEL = YPrPb, Y = A
IN
1, Pb = A
IN
2, Pr = A
IN
3
Clear NEWAV_MODE, SAV/EAV to suit ADV video encoders
MWE enable manual window
BLM optimization
ADI recommended
Hidden space
ADC configuration
User space
