ADSY8401
LEVEL SHIFTER CHARACTERISTICS
LEVEL SHIFTER TIMING CHARACTERISTICS
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
DO1
DO2
DO3
DO4
DO5
DO6
DO7
DO8
DO9T
DO10T
DO11T
DI9
DI10
DI11
DO9C
DO10C
DO11C
INVERTING
COMPLEMENTARY
Figure 6. Level Shifter Timing Characteristics
INVERTING AND COMPLEMENTARY LEVEL SHIFTER TIMING
INPUTS
t11
t12
INVERTING
OUTPUTS
t15
t17
t16
t18
NONINVERTING
OUTPUTS
t13
t14
Figure 7. Inverting and Complementary Level Shifter Timing
Table 4.
Parameter
Conditions
Min
Typ
Max
Unit
LEVEL SHIFTER SECTION
Output Rise, Fall Times, tr, tf
DO1–DO8, DO9T–DO11T, DO9C–DO11C
DO1–DO8
TA min to TA max
CL = 40 pF
CL = 300 pF
20
130
30
150
ns
ns
Propagation Delay times, t11, t12, t13, t14
DO1–DO8, DO9T–DO11T, DO9C–DO11C
DO1–DO8
Propagation Delay Skew, t15, t16
DO1–DO8
CL = 40 pF
CL = 300 pF
CL = 40 pF
23
60
50
80
ns
ns
2
ns
ns
Propagation Delay Skew, t15, t16, t17, t18
DO1–DO8 to DO9T–DO11T and DO9C–DO11C
CL = 40 pF
4
