ADSP-BF542/ADSP-BF544/ADSP-BF547/ADSP-BF548/ADSP-BF549
Figure 58 displays a host terminating an ultra DMA data-out
burst.
ATAPI_DMARQ
ATAPI_DMACK
tLI
tLI
tMLI
tACK
ATAPI_DIOW
tSS
tLI
ATAPI_IORDY
ATAPI_DIOR
ATAPI_D0–15
ATAPI ADDR
tACK
tCVS
tCVH
tACK
Figure 58. Host terminating an Ultra DMA Data-Out Burst1
1 This material is adapted from ATAPI-6 (INCITS 361-2002[R2007] and is used with permission of the American National Standards Institute (ANSI) on behalf of the
Information Technology Industry Council (“ITIC”). Copies of ATAPI-6 (INCITS 361-2002[R2007] can be purchased from ANSI.
Figure 59 displays a device terminating an ultra DMA data-out
burst.
ATAPI_DMARQ
ATAPI_DMACK
tLI
tMLI
tACK
ATAPI_DIOW
ATAPI_IORDY
ATAPI_DIOR
ATAPI_D0–15
ATAPI ADDR
tRFS
tLI
tMLI
tACK
tCVS
tCVH
tACK
Figure 59. Device Terminating an Ultra DMA Data-Out Burst1
1 This material is adapted from ATAPI-6 (INCITS 361-2002[R2007] and is used with permission of the American National Standards Institute (ANSI) on behalf of the
Information Technology Industry Council (“ITIC”). Copies of ATAPI-6 (INCITS 361-2002[R2007] can be purchased from ANSI.
Rev. C
|
Page 84 of 100
|
