ADSP-BF542/ADSP-BF544/ADSP-BF547/ADSP-BF548/ADSP-BF549
Figure 54 displays a device terminating an ultra DMA data-in
burst.
ATAPI_DMARQ
ATAPI_DMACK
ATAPI_DIOW
ATAPI_DIOR
ATAPI_IORDY
ATAPI_D0–15
ATAPI ADDR
tLI
tLI
tMLI
tACK
tLI
tACK
tAZ
tCVS
tCVH
tZAH
tACK
Figure 54. Device Terminating an Ultra DMA Data-In Burst1
1 This material is adapted from ATAPI-6 (INCITS 361-2002[R2007] and is used with permission of the American National Standards Institute (ANSI) on behalf of the
Information Technology Industry Council (“ITIC”). Copies of ATAPI-6 (INCITS 361-2002[R2007] can be purchased from ANSI.
Figure 55 displays a host terminating an ultra DMA data-in
burst.
ATAPI_DMARQ
tLI
tMLI
ATAPI_DMACK
ATAPI_DIOW
ATAPI_DIOR
ATAPI_IORDY
ATAPI_D0–15
ATAPI ADDR
tACK
tZAH
tRP
tACK
tLI
tCVS
tCVH
tACK
Figure 55. Host Terminating an Ultra DMA Data-In Burst1
1 This material is adapted from ATAPI-6 (INCITS 361-2002[R2007] and is used with permission of the American National Standards Institute (ANSI) on behalf of the
Information Technology Industry Council (“ITIC”). Copies of ATAPI-6 (INCITS 361-2002[R2007] can be purchased from ANSI.
Rev. C
|
Page 81 of 100
|
February 2010
