AD9364
Data Sheet
Pin No.
Type1 Mnemonic
Description
C5, C6, D5, D6
I
CTRL_IN0 to CTRL_IN3
Control Inputs. Use C5, C6, D5, and D6 for manual Rx gain and Tx attenuation
control.
D2
I
VDDA1P3_RX_RF
Receiver 1.3 V Supply Input. Connect to D3.
D4, E4 to E6,
F4 to F6, G4
O
CTRL_OUT0, CTRL_OUT1 to
CTRL_OUT3, CTRL_OUT6 to
CTRL_OUT4, CTRL_OUT7
Control Outputs. These pins are multipurpose outputs that have programmable
functionality.
D7
I/O
I/O
I/O
I/O
I/O
I
P0_D9/TX_D4_P
P0_D7/TX_D3_P
P0_D5/TX_D2_P
P0_D3/TX_D1_P
P0_D1/TX_D0_P
VSSD
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D9, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D4_P) can function as part of the LVDS 6-
bit Tx differential input bus with internal LVDS termination.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D7, it functions as part of the 12-bit bidirectional parallel CMOS level Data
Port 0. Alternatively, this pin (TX_D3_P) can function as part of the LVDS 6-bit Tx
differential input bus with internal LVDS termination.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D5, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D2_P) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D3, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D1_P) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
D8
D9
D10
D11
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D1, it functions as part of the 12-bit bidirectional parallel CMOS level Data
Port 0. Alternatively, this pin (TX_D0_P) can function as part of the LVDS 6-bit Tx
differential input bus with internal LVDS termination.
Digital Ground. Tie these pins directly to the VSSA analog ground on the printed
circuit board (one ground plane).
D12, F7, F9,
F11, G12, H7,
H10, K12
E2
E3
E7
I
I
VDDA1P3_RX_LO
VDDA1P3_TX_LO_BUFFER
P0_D11/TX_D5_P
Receive LO 1.3 V Supply Input.
1.3 V Supply Input.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D11, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D5_P) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
I/O
E8
I/O
I/O
I/O
I/O
I/O
I
P0_D8/TX_D4_N
P0_D6/TX_D3_N
P0_D4/TX_D2_N
P0_D2/TX_D1_N
P0_D0/TX_D0_N
VDDA1P3_RX_VCO_LDO
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D8, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D4_N) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D6, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D3_N) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D4, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D2_N) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D2, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D1_N) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
E9
E10
E11
E12
F2
Digital Data Port P0/Transmit Differential Input Bus. This is a dual function pin.
As P0_D0, it functions as part of the 12-bit, bidirectional, parallel CMOS level
Data Port 0. Alternatively, this pin (TX_D0_N) can function as part of the LVDS
6-bit Tx differential input bus with internal LVDS termination.
Receive VCO LDO 1.3 V Supply Input. Connect F2 to E2.
Rev. B | Page 12 of 32
