TERMINOLOGY
Integral Nonlinearity
Gain Error
Integral nonlinearity is the maximum deviation from a straight
line passing through the endpoints of the ADC transfer function.
The endpoints of the transfer function are zero scale, a point 1 LSB
below the first code transition, and full scale, a point 1 LSB
above the last code transition.
Gain error is the deviation of the last code transition (111…110)
to (111…111) from the ideal (that is, VREF – 1 LSB) after the
offset error is adjusted out.
Track-and-Hold Acquisition Time
The track-and-hold amplifier enters the acquisition phase on
the fifth falling edge of DCLK after the start bit has been
detected. Three DCLK cycles are allowed for the track-and-hold
acquisition time. The input signal is fully acquired to the 12-bit
level within this time even with the maximum specified DCLK
frequency. See the Analog Input section for more details.
Differential Nonlinearity
Differential nonlinearity is the difference between the measured
and the ideal 1 LSB change between any two adjacent codes in
the ADC.
Offset Error
Offset error is the deviation of the first code transition (00…000)
On Resistance
to (00…001) from the ideal, that is, AGND + 1 LSB.
On resistance is a measure of the ohmic resistance between the
drain and source of the switch drivers.
