AD73360
Figure 23 shows a comparison of SNR results achieved by vary-
ing either the Decimation Rate Setting or the DMCLK Rate
Settings.
point at 34 kHz; these are the only filters that must be imple-
mented external to the AD73360 to prevent aliasing of the
sampled signal. Since the ADC uses a highly oversampled ap-
proach that transfers the bulk of the antialiasing filtering into the
digital domain, the off-chip antialiasing filter need only be of a
low order. It is recommended that for optimum performance the
capacitors used for the antialiasing filter be of high quality di-
electric (NPO).
81
DMCLK = MCLK
80
79
78
77
76
The AD73360’s on-chip 38 dB preamplifier can be enabled
when there is not enough gain in the input circuit; the preampli-
fier is configured by bits IGS0–2 of CRD. The total gain must
be configured to ensure that a full-scale input signal produces a
signal level at the input to the sigma-delta modulator of the
ADC that does not exceed the maximum input range.
REDUCED
DMCLK
75
74
73
72
71
The dc biasing of the analog input signal is accomplished with
an on-chip voltage reference. If the input signal is not biased at
the internal reference level (via REFOUT), then it must be
ac-coupled with external coupling capacitors. CIN should be
0.1 µF or larger. The dc biasing of the input can then be accom-
plished using resistors to REFOUT as in Figure 25.
8
16
24
32
40
48
56
64
SAMPLING FREQUENCY – kHz
Figure 23. Comparison of DMCLK and Decimation Rate
Settings
Encoder Group Delay
The AD73360 implementation offers a very low level of group
delay, which is given by the following relationship:
CIN
100⍀
100⍀
VINPx
VINNx
10k⍀
10k⍀
VIN
CIN
Group Delay (Decimator) = Order × ((M–1)/2) × Tdec
where:
0.047F
0.047F
TO INPUT BIAS
CIRCUITRY
Order is the order of the decimator (= 3),
M is the decimation factor (= 32) and
Tdec is the decimation sample interval (= 1/2.048e6)
REFOUT
VOLTAGE
REFERENCE
REFCAP
0.1F
Figure 25. Example Circuit for Differential Input
(AC Coupling)
=> Group Delay (Decimator) = 3 × (32–1)/2 × (1/2.048e6)
= 22.7 µs
Figures 26 and 27 detail ac- and dc-coupled input circuits for
single-ended operation respectively.
If final filtering is implemented in the DSP, the final filter’s
group delay must be taken into account when calculating overall
group delay.
CIN
100⍀
VINPx
VINNx
VIN
DESIGN CONSIDERATIONS
10k⍀
0.047F
Analog Inputs
The AD73360 features six signal conditioning inputs. Each
signal conditioning block allows the AD73360 to be used with
either a single-ended or differential signal. The applied signal
can also be inverted internally by the AD73360 if required. The
analog input signal to the AD73360 can be dc-coupled, pro-
vided that the dc bias level of the input signal is the same as the
internal reference level (REFOUT). Figure 24 shows the recom-
mended differential input circuit for the AD73360. The circuit
of Figure 24 implements first-order low-pass filters with a 3 dB
REFOUT
VOLTAGE
REFERENCE
REFCAP
0.1F
Figure 26. Example Circuit for Single-Ended Input
(AC Coupling)
100⍀
VINPx
VINNx
VIN
100⍀
100⍀
VINPx
VINNx
0.047F
VIN
REFOUT
0.047F
0.047F
VOLTAGE
REFERENCE
TO INPUT BIAS
CIRCUITRY
REFCAP
0.1F
REFOUT
VOLTAGE
REFERENCE
REFCAP
0.1F
Figure 27. Example Circuit for Single-Ended Input
(DC Coupling)
Figure 24. Example Circuit for Differential Input
(DC Coupling)
REV. B
–25–
